12V 100Ah Eco Series LiFePO4 Battery (1.28kWh)
12V 100Ah Eco Series LiFePO4 Battery (1.28kWh) is backordered and will ship as soon as it is back in stock.
Description
Description
Why we carry Epoch: an American company that stands behind its batteries, answers the phone, and offers real tech support for boat and RV owners. Read why we buy Epoch
Shop the Epoch 12V 100Ah Eco Series LiFePO4 battery (1.28kWh). A 21-lb Group 24 drop-in replacement featuring a smart BMS, 4,500+ cycles & 6-yr warranty.
Features
- Drop-in Group 24 size at 21 lb
- 4,500+ cycle life
- Smart BMS: overcharge, over-discharge, over-current, short circuit, high/low temperature protection
- Low-temperature charge block below 32°F (0°C)
- IP54 splash and dust resistant (not submersible)
- Expandable up to 4 in series and 16 in parallel
- Maintenance-free LiFePO4 chemistry
- 6-year manufacturer warranty
Specifications
| Epoch part number | 12100-ECO |
| Electrical | |
|---|---|
| Capacity | 100Ah (1,280Wh) |
| Nominal voltage | 12.8V |
| Max charge voltage | 14.6V |
| Operating voltage range | 10.0V to 14.6V |
| Max continuous discharge | 100A |
| Peak discharge | 300A for up to 5 s |
| Max continuous charge | 100A |
| Recommended charge current | 50A |
| Series / parallel | Up to 4 in series, 16 in parallel (4S16P max) |
| Cells | Prismatic LiFePO4, 4S1P |
| Cycle life | 4,500+ cycles |
| Cold cranking amps | Not cranking-rated |
| Charger settings | |
| Bulk / absorption | 14.2V to 14.4V |
| Float | 13.3V to 13.6V (off preferred where supported) |
| Equalization | Disabled |
| Temperature | |
| Charging | 32°F to 131°F (0°C to 55°C) |
| Discharging | -4°F to 140°F (-20°C to 60°C) |
| Storage | 32°F to 95°F (0°C to 35°C) recommended |
| Self-heating | No |
| Physical | |
| Weight | 21 lb (9.5 kg) |
| Dimensions (L × W × H) | 10¼ × 6¾ × 9 in (260 × 171 × 229 mm) |
| BCI group / footprint | Group 24 |
| Terminals | M8 female, 8–12 N·m (71–106 in-lb) |
| Water resistance | IP54 (splash resistant, not submersible) |
| Bluetooth | No |
| Communications | None (state of charge needs an external battery monitor) |
| Warranty | 6 years |
Dimensions
From Epoch: Epoch datasheet (PDF) · Epoch product page
Specs are from Epoch's published datasheet. Confirm system voltage, charger settings, wiring and installation requirements before use.
Ships directly from Epoch Batteries.
