Description
Description
Victron Phoenix Inverter 24/800 GFCI: 800VA = 650 watts continuous
A 24V pure sine wave inverter from Victron Energy with 120V AC output.
Why the VA number isn't the watts: Victron rates its inverters in VA (volt-amps). This one delivers 650W continuous at 77°F (25°C) and 1,500W peak for motor and compressor start-up. Size your loads around 650W, not 800W. Compare all Victron inverters →
What it will run on a boat
At 650W it handles electronics and entertainment gear, satellite internet, LED lighting and small appliances that stay under its rating. Add up everything you'll run at the same time and leave 20–25% headroom.
Battery draw and wiring
At full continuous output it pulls roughly 30 amps from a 24V battery bank (650W ÷ 24V ÷ 90% efficiency). Size the battery cables, DC fuse and battery bank for that current. The manual lists Victron's recommended cable and fuse sizes for this model.
Mounting it in a hot engine room?
Continuous output drops as the temperature rises: 560W at 104°F (40°C). In the Keys an engine room or lazarette can easily run hotter than 104°F, so size for the hottest spot you'll mount it and give it airflow.
Idle draw at anchor
Switched on with nothing plugged in, it uses about 7W, roughly 7Ah per day from a 24V bank. ECO mode cuts that to 1.5 W when you don't need full power.
Specifications (from Victron)
| Battery voltage | 24 V |
| DC input range | 18.4–34 V |
| AC output | 120 V |
| Continuous power @ 77°F (25°C) | 800 VA / 650 W |
| Continuous power @ 104°F (40°C) | 560 W |
| Peak power | 1,500 W |
| Max efficiency | 90 % |
| Idle draw | 7 W |
| Communication port | VE.Direct |
| Protection rating | IP21 |
| Operating temperature | -40°F to 149°F (-40 to 65°C) |
| Weight | 12.1 lb (5.5 kg) |
| Dimensions (H x W x D) | 4.1 x 8.5 x 12.0 in (105 x 216 x 305 mm) |
| Safety standards | EN-IEC 60335-1,EN-IEC 62109-1,UL 458 |
| Warranty | 5 years (Victron) |
| Victron part number | PIN241800510 |
| UPC / EAN | 8719076050223 |
Documents
Buying from OnBoard
We install Victron systems on boats in Marathon and the Florida Keys. Not sure which size you need? Call 305-998-4300 or email contact@onboardmarinegoods.com and we'll help you size it and plan the wiring before you buy. Local pickup is available at our shop on US-1 in Marathon.
