Victron Inverter 24/250 120V VE.Direct Nema 5-15R [PIN241250500]
Pickup available at our Marathon storefront
Available for pickup or shipping
Victron Inverter 24/250 120V VE.Direct Nema 5-15R [PIN241250500] is backordered and will ship as soon as it is back in stock.
(Ship Note)
Ready to order
Pickup currently unavailable at Marathon Storefront
- Expert technical support
- Secure checkout
- Fast shipping
Need help choosing? Call our marine experts at (305) 998-4300.
Delivery and Shipping
Delivery and Shipping
Items in stock gernally ship same day.
Items that require splicing will be made in order from the date it is ordered. If you want something fast, just give us a call.
Any items that require freight will be quoted and shipped once approved.
Shipping in the keys can be delieverd same day for a fee.
Victron Inverter 24/250 120V VE.Direct Nema 5-15R [PIN241250500]
Victron Inverter 24/250 120V VE.Direct Nema 5-15R [PIN241250500] is backordered and will ship as soon as it is back in stock.
Description
Description
Victron Phoenix Inverter 24/250 NEMA 5-15R: 250VA = 200 watts continuous
A 24V pure sine wave inverter from Victron Energy with 120V AC output.
Why the VA number isn't the watts: Victron rates its inverters in VA (volt-amps). This one delivers 200W continuous at 77°F (25°C). Size your loads around 200W, not 250W. Compare all Victron inverters →
What it will run on a boat
At 200W it handles phone and laptop chargers, a small LED TV, satellite internet gear and other electronics. Add up everything you'll run at the same time and leave 20–25% headroom.
Battery draw and wiring
At full continuous output it pulls roughly 9 amps from a 24V battery bank (200W ÷ 24V ÷ 90% efficiency). Size the battery cables, DC fuse and battery bank for that current. The manual lists Victron's recommended cable and fuse sizes for this model.
Specifications (from Victron)
| Battery voltage | 24 V |
| AC output | 120 V |
| Continuous power @ 77°F (25°C) | 250 VA / 200 W |
| Warranty | 5 years (Victron) |
| Victron part number | PIN241250500 |
| UPC / EAN | 8719076073895 |
Continuous rating taken from the same-size Victron VE.Direct model; check the datasheet for full figures.
