Victron BlueSolar MPPT 150/100-Tr VE.Can [SCC115110420]
Victron BlueSolar MPPT 150/100-Tr VE.Can [SCC115110420] is backordered and will ship as soon as it is back in stock.
Description
Description
Victron BlueSolar MPPT 150/100-Tr VE.Can
Victron BlueSolar MPPT solar charge controllers track the maximum power point of your panels to harvest more energy, especially in hazy or changing light, with adaptive multi-stage charging for long battery life.
Specifications (from Victron)
| Rated Charge Current | 100 A |
| Battery voltage | 12V / 24V / 48V Auto Select (software tool needed to select 36V) |
| Maximum PV Open Circuit Voltage | 150 V |
| Maximum PV short circuit current per tracker | 70 A |
| Maximum efficiency | 98 % |
| Data Communication | VE.Direct,VE.Can |
| Low Voltage Load Disconnect | 11.1V / 22.2V or 11.8V / 23.6V or Battery Life algorithm |
| Low Voltage Load Reconnect | 13.1V / 26.2V / 52.4V or 14V / 28V / 56V or Battery Life algorithm |
| Maximum Altitude | 5,000 m (16,400 ft) |
| Nominal PV power at 48 V | 5,800 W |
| Maximum humidity (non-condensing) | 95 % |
| Nominal PV power at 12 V | 1,450 W |
| Nominal PV power at 24 V | 2,900 W |
| Nominal PV power at 36V | 4,350 W |
| Environmental Condition | Indoor, unconditioned |
| Charge algorithm | Multi-stage adaptive (adjustable) |
| Charge voltage absorption | 14.4V / 28.8V / 57.6V (adjustable) |
| Charge voltage float | 13.8V / 27.6V / 55.2V (adjustable) |
| Temperature Sensor | Internal |
| Temperature Compensation at 48V | -64 mV/°C |
| Number of trackers | 1 |
| Operating temperature range | -22°F to 140°F (-30 to 60°C) |
| Pollution Degree | PD3 |
| Programmable relay | DPST AC rating: 240VAC / 4A, DC rating: 4A up to 35VDC, 1A up to 60VDC |
| Protections | PV reverse polarity,Output short-circuit,Excessive temperature |
| Number of synchronised parallel operating units with VE.Can | 25 |
| Remote on/off terminal | Yes |
| Self-consumption | Less than 35mA @ 12V / 20mA @ 48V |
| Start-up PV DC voltage | The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V |
| Temperature Compensation at 12V | -16 mV/°C |
| Warranty | 5 years (Victron) |
| Victron part number | SCC115110420 |
| UPC / EAN | 8719076049852 |
| Country of origin | India |
Documents
- BlueSolar charge controller MPPT 250/70-Tr VE.Can, 150/100-Tr VE.Can & 250/100-Tr VE.Can (datasheet)
- BlueSolar and SmartSolar Charge Controller MPPT - Overview (datasheet)
- Victron product page (manuals, drawings, certificates)
From Victron
A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, BlueSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. BlueSolar maintains battery health, extending its life.
