Victron MultiPlus-II 12/4k/160-50 2x120V 50/60Hz [PMP122405210]
Pickup available at our Marathon storefront
FULFILLMENT OPTIONS
Available for pickup or shipping
Victron MultiPlus-II 12/4k/160-50 2x120V 50/60Hz [PMP122405210] is backordered and will ship as soon as it is back in stock.
Ready to order
Pickup available at Marathon Storefront
Usually ready in 24 hours
- Expert technical support
- Secure checkout
- Fast shipping
Need help choosing? Call our marine experts at (305) 998-4300.
Delivery and Shipping
Delivery and Shipping
Items in stock gernally ship same day.
Items that require splicing will be made in order from the date it is ordered. If you want something fast, just give us a call.
Any items that require freight will be quoted and shipped once approved.
Shipping in the keys can be delieverd same day for a fee.
Victron MultiPlus-II 12/4k/160-50 2x120V 50/60Hz [PMP122405210]
Victron MultiPlus-II 12/4k/160-50 2x120V 50/60Hz [PMP122405210] is backordered and will ship as soon as it is back in stock.
Description
Description
Special Order: Estimated working time 5 business days. We order this unit from Victron Energy for you. Questions about fit or lead time? Contact us.
Victron MultiPlus-II 12/4k/160-50 2x120V 50/60Hz
A one-box solution for North American 50A 120/240V split-phase shore power. On a split-phase supply it passes both legs through for charging and loads. When inverting, it ties L1 and L2 together so both sides of your panel get 120V (240V loads only run on shore or generator). Includes PowerControl, PowerAssist, input current limit and two AC outputs.
Specifications
- Continuous output at 77°F (25°C): 3,400 W
- Continuous output at 104°F (40°C): 3,100 W
- Continuous output at 149°F (65°C): 2,400 W
- Peak power: 6,000 W
- Battery voltage: 12 V DC (input range 9.5–17 VDC)
- AC output: 120 V, 60 Hz pure sine wave
- Max battery charge current: 160 A
- Transfer switch: 50A
- AC inputs: 1
- Max efficiency: 93%
- Zero-load power: 18 W
- Communication: VE.Bus
- Protection: IP22
- Warranty: 5 years (Victron)
Dimensions & weight
- Size (H × W × D): 25.6 × 10.8 × 6.5 in (650 × 275 × 165 mm)
- Weight: 55.1 lb (25 kg)
