Victron Blue Smart IP22 Charger 24/8 (1) 120V NEMA 5-15 [BPC240845102]
Victron Blue Smart IP22 Charger 24/8 (1) 120V NEMA 5-15 [BPC240845102] is backordered and will ship as soon as it is back in stock.
(Ship Note)
Ready to order
- Expert technical support
- Secure checkout
- Fast shipping
Need help choosing? Call our marine experts at (305) 998-4300.
Delivery and Shipping
Delivery and Shipping
Items in stock gernally ship same day.
Items that require splicing will be made in order from the date it is ordered. If you want something fast, just give us a call.
Any items that require freight will be quoted and shipped once approved.
Shipping in the keys can be delieverd same day for a fee.
Victron Blue Smart IP22 Charger 24/8 (1) 120V NEMA 5-15 [BPC240845102] is backordered and will ship as soon as it is back in stock.
Description
Description
Victron Blue Smart IP22 Charger 24/8 (1) 120V NEMA 5-15
Victron Blue Smart IP22 chargers are compact multi-stage battery chargers with Bluetooth set-up and monitoring through the free VictronConnect app.
Specifications (from Victron)
| Charge Current Night or Low Mode | 4 A |
| Charge Current Normal Mode (Nominal Value) | 8 A |
| Nominal battery voltage | 24 V |
| Efficiency | 94 % |
| Communication Ports | Bluetooth |
| Bluetooth | Yes |
| No-load power consumption | 0.5 W |
| Number of charge outputs | 1 |
| Operating temperature range | -4°F to 122°F (-20 to 50°C) |
| Programmable | Yes |
| Protections | Battery reverse polarity (fuse),Output short-circuit,Over temperature |
| Temperature Compensation (adjustable) | -32 mV/°C |
| Temperature Sensor | Optional (Smart Battery Sense) |
| Maximum humidity (non-condensing) | 98 % |
| AC input frequency range | 45–65 Hz |
| Can be used as power supply | Yes |
| Charge algorithm | Adaptive, 6-stage |
| Charge voltage Absorption | Normal: 28.8V High: 29.4V Lithium: 28.4V |
| Charge voltage float | Normal: 27.6V High: 27.6V Li-ion: 27.0V |
| Charge voltage storage | Normal: 26.4V High: 26.4V Li-ion: 27.0V |
| Forced cooling | Yes |
| Lithium compatible | Yes |
| AC connection terminal type | Cable of 1.8 meter (6 feet) with US NEMA 5-15 plug |
| Battery connection terminal type | Screw terminals 16 mm² (6 AWG) |
| Protection category | IP22 |
| Material | Aluminium |
| Colour | Blue (RAL 5012) |
| Emission | EN 55014-1,EN-IEC 61000-3-2,EN-IEC 61000-6-3 |
| Automotive directive | ECE R10-5 |
| Immunity | EN 55014-2,EN-IEC 61000-3-3, EN-IEC 61000-6-2,EN-IEC 61000-6-3 |
| Warranty | 5 years (Victron) |
| Victron part number | BPC240845102 |
| UPC / EAN | 8719076050643 |
| Country of origin | India |
Documents
- Blue Smart IP22 Charger (datasheet)
- Blue Smart IP22 Charger - 120V (datasheet)
- Victron product page (manuals, drawings, certificates)
From Victron
The Blue Smart IP22 Charger is the new professional battery charger with built-in Bluetooth. The Blue Smart IP22 Charger can be used on devices in your workshop and on motor vehicles, such as (classic) cars; motorbikes; boats and camper-vans.
