Description
Description
Genuine Mantus stainless steel anchor shackle with hex-head pin for a secure ground-tackle connection. Select the shackle size required for the rode and anchor system.
Mantus Anchor Shackles
Stainless steel anchor shackle designed for the job:
- A flush hex head allows for smooth passage through the bow roller
- A socket wrench or a crescent wrench could be easily used to open or close the pin even after many months of use.
- A hole in the hex head is designed to safety wire the pin to prevent pin loosening.
- Mantus boat anchor shackles are forged from 2205 Duplex stainless steel.
Duplex Stainless anchor shackles with Breaking Strength five times the working load limit:
| Working Load Limit (lbs) Recommendations* | Ultimate Breaking Strength (lbs) | |||||
| Size | 2205 Duplex Forged Stainless Shackles | Hi Test G4 Chain (artificially inflated use the bold number) | G3 Chain Proof-coil,BBB | 2205 Drop Forged Stainless Shackles | Hi Test G4 Chain | G3 Chain Proof-coil,BBB |
| 1/4 | 1,300 | 2,600/1,950 | 1,300 | 6,500 | 7,800 | 5,200 |
| 5/16 | 1,850 | 3,900/2,900 | 1,900 | 9,100 | 11,700 | 7,600 |
| 3/8 | 1,950 | 5,400/4,050 | 2,650 | 9,750 | 16,200 | 10,600 |
| 7/16 | 2,600 | 7,200/5,400 | N/A | 13,000 | 21,600 | N/A |
| 1/2 | 3,900 | 9,200/6,900 | 4,500 | 19,500 | 27,600 | 18,000 |
| 5/8 | 5,200 | 13,000/9,750 | 26,000 | 39,000 | ||
| 3/4 | 9.300 | 37,000 | ||||
*These are manufacturer’s recommendations and often differ from one marine manufacturer to another. Our anchor chain shackles are strong enough to use with Hi Test Chain—just pick one size larger than the chain. *The working load limit called out on our anchor shackles is 1/5 th of the breaking strength. So, when sizing our shackles, it is more useful to compare the ultimate breaking strength of the shackle to that of the chain.
Using stainless steel shackle with galvanized chain:
- When sizing a stainless steel shackle for your anchor and Grade 30 galvanized chain, pick a shackle one size larger than the chain and the shackle will be the same strength as the chain.
- When sizing a stainless steel shackle for your anchor and (G43) Grade 40 galvanized chain, only a shackle one size larger will fit and the shackle will be 60 – 70% the strength of the chain. We recommend using a Mantus swivel to match the strength of the shackle connection to that of the Grade 40 chain.
Using galvanized shackle with galvanized chain:
- When sizing a galvanized steel shackle for your anchor and Grade 30 galvanized chain, pick a shackle the same size as your chain.
- When sizing a galvanized steel shackle for your anchor and Grade 40 galvanized chain, pick an anchor shackle one size larger than the chain and the shackle will be the same strength as the chain.
